Product Description
Clark push-button control switch for electric lift truck circuits. The CL 7004078 is a direct replacement control switch featuring a molded thermoplastic body with silver alloy contacts for reliable conductivity and long contact life. Rated for continuous duty operation at 24VDC with 10A maximum capacity. Ideal for GEX and ECX series electric lift trucks requiring factory-spec replacement components for control circuit applications.
Specifications
Electrical
| Switch Voltage Rating | 24VDC nominal |
| Current Carrying Capacity | 10A maximum at 24VDC |
Material & Construction
| Switch Housing Material | Molded thermoplastic enclosure |
| Contact Material | Silver alloy |
Part Numbers
| Part Number | CL 7004078 |
Performance
| Duty Cycle | Continuous duty (100% at rated current) |
| Service Life | Rated for 100,000 mechanical actuations minimum |
Frequently Asked Questions
Q: What is the voltage and current rating for the CL 7004078 push button switch?
A: The CL 7004078 is rated for 24VDC nominal with a maximum current carrying capacity of 10A at 24VDC. This switch is designed specifically for 24-volt DC control circuits and does not support other voltage levels.
Q: Which Clark lift truck series use the CL 7004078 switch?
A: The CL 7004078 is compatible with the Clark GEX and ECX series electric lift trucks. Verify your specific truck model and control circuit before ordering, as application varies within these series.
Q: What is the service life and duty cycle of the CL 7004078?
A: The CL 7004078 is rated for continuous duty operation at 100 percent of rated current (10A at 24VDC) with a service life of 100,000 mechanical cycles. This durability makes it suitable for high-frequency control applications in electric lift trucks.
Q: What materials are used in the CL 7004078 switch construction?
A: The CL 7004078 features a molded thermoplastic enclosure with silver alloy contacts. The thermoplastic body provides electrical insulation and mechanical protection, while silver alloy contacts ensure reliable conductivity and long contact life.
Q: Are there cross-reference or equivalent part numbers for the CL 7004078?
A: No cross-reference or superseding part numbers have been reported for the CL 7004078. Use the exact OEM part number when ordering replacement switches for GEX and ECX series trucks.
