Product Description
Industrial-grade LP 393-9904 switch for electric lift truck applications, panel-mount, momentary contact, rated for 24VDC/10A. Silver alloy contacts, glass-filled nylon housing, 13 mm actuator diameter, mechanical endurance 200,000 cycles.
Specifications
Electrical
| Rated Voltage | 24VDC maximum |
| Contact Rating | 10A resistive load at 24VDC |
| Dielectric Strength | 1000VAC for 1 minute |
Material
| Actuator Material | Polycarbonate actuator button |
| Body Material | Glass-filled nylon housing |
Part Numbers
| Manufacturer Part Number | LP 393-9904 |
| OEM Part Number | LP 393-9904 |
Performance
| Electrical Endurance | 50,000 cycles at rated load |
| Mechanical Endurance | 200,000 cycles |
Frequently Asked Questions
Q: What are the electrical specifications for the LP 393-9904 switch?
A: The LP 393-9904 is rated for 24VDC maximum with a contact rating of 10A resistive load at 24VDC. Dielectric strength is 1000VAC for 1 minute. Silver alloy contacts ensure reliable conductivity in industrial lift truck applications.
Q: What is the mechanical endurance rating for this momentary contact switch?
A: This switch is rated for 200,000 mechanical cycles, making it suitable for heavy-duty material handling equipment where frequent activation occurs in warehouse and dock environments.
Q: What materials are used in the LP 393-9904 construction?
A: The housing is constructed from glass-filled nylon for durability and chemical resistance. The actuator button is polycarbonate. Silver alloy contacts provide reliable electrical performance and extended service life.
Q: What is the actuator diameter for the LP 393-9904?
A: The actuator diameter is 13 mm. This is a panel-mount switch designed for standard industrial control panel openings on electric lift trucks.
Q: Is this switch compatible with different lift truck brands?
A: The LP 393-9904 is designed for electric lift truck applications across multiple OEM manufacturers. Verify your specific model and voltage system (24VDC) matches before ordering.
