Product Description
Forward/Reverse Control Switch for Electric Lift Trucks
The SW-1283 is a panel-mount forward/reverse selector switch designed for electric lift truck control applications. Compatible with LINDE 1283 and 1218 series vehicles, this switch features a double pole, double throw configuration rated for 10A at 24VDC. Built with high-impact nylon housing and silver alloy contacts, the SW-1283 delivers reliable directional control for mast, drive, and hydraulic system management in warehouse and dock environments.
Specifications
Functional Specifications
| Switch Type | Forward/Reverse Selector (Double Pole, Double Throw) |
| Mount Style | Panel Mount |
Electrical
| Rated Voltage | 24 VDC maximum circuit voltage |
| Rated Current | 10A resistive load at 24 VDC |
| Contact Material | Silver alloy contacts |
Material & Construction
| Switch Housing Material | High-impact nylon polymer per ASTM D4066 |
Part Numbers & Compatibility
| Manufacturer Part Number | SW-1283 |
| Cross-Reference Part Numbers | 12833584501, LB32-601A, LP393-8125, TO2I5930, TY00591-05049-81, TY00591-32276-81, TY00591-57447-81, TY00591-32247-81, HY800076075, CL444113 |
| Supersedes | Replaces 12833584501, supersedes LB32-601A |
| Compatible Makes | LINDE, Toyota, Hyster, Clark |
| Compatible Models | LINDE 1283, LINDE 1218 series |
Frequently Asked Questions
Q: What does the SW-1283 forward/reverse selector switch do?
A: The SW-1283 is a panel-mount forward/reverse selector switch for electric lift truck control systems. It uses a double pole, double throw configuration to control directional movement of the lift truck mast, drive, or hydraulic systems between forward and reverse modes.
Q: Which LINDE lift truck models use the SW-1283?
A: The SW-1283 is compatible with LINDE 1283 and 1218 series electric lift trucks. It also cross-references to part number 12833584501 and covers equivalent part numbers including LB32-601A, LP393-8125, TO2I5930, and multiple TY00591 Toyota variants.
Q: What are the electrical ratings and contact specifications for the SW-1283?
A: The SW-1283 is rated for 10A at 24VDC. It features silver alloy contacts that provide reliable conductivity and durability under repeated switching cycles. The double pole, double throw design allows simultaneous control of forward and reverse circuits.
Q: What materials are used in the SW-1283 construction?
A: The SW-1283 housing is constructed from high-impact nylon, which resists cracking and provides durability in industrial environments. The contacts are silver alloy, which maintains low contact resistance and resists corrosion over extended use.
Q: How do I verify the SW-1283 is the correct replacement?
A: Locate the part number on your lift truck control panel or in documentation. Cross-reference against the following equivalents: SW-1283, 12833584501, LB32-601A, LP393-8125, TO2I5930, TY00591-05049-81, TY00591-32276-81, TY00591-57447-81, or TY00591-32247-81. Verify operating voltage is 24VDC.
Q: When does the SW-1283 need replacement?
A: Replace the SW-1283 if the lift truck does not respond to forward or reverse commands, moves intermittently, shows visible cracks in the nylon housing, or has corrosion on the contacts. High-cycle use typically results in a service life of 4 to 8 years.
