Product Description
SW-1373 switch for electric lift trucks, manufacturer part number SW-1373, with cross-reference TY00591-60714-81, YT800058861, and 078927. Features SPST momentary operation, copper alloy contacts, 12VDC rating, M12 threaded bushing, panel mount, and 0.250 inch tab terminals for compatibility across various industrial lift truck applications.
Specifications
Electrical
| Rated Voltage | 12VDC nominal |
| Current Rating | 10A continuous at 12VDC |
| Connector Type | Tab terminals, 0.250 inch male |
Material & Construction
| Housing Material | Glass-filled thermoset plastic |
| Actuator Material | Nickel-plated steel |
Part Numbers
| Manufacturer Part Number | SW-1373 |
| Cross-Reference Part Numbers | TY00591-60714-81, YT800058861, 078927 |
| Equivalent Part Number | SW1373 |
Performance Specifications
| Electrical Life | 100,000 cycles at rated load |
| Mechanical Life | 1,000,000 cycles |
Frequently Asked Questions
Q: What are the electrical ratings for the SW-1373 switch?
A: The SW-1373 is rated at 12VDC nominal with a maximum continuous current of 10A. It features SPST momentary operation with copper alloy contacts designed for reliable performance in electric lift truck control circuits.
Q: What lift truck models does the SW-1373 fit?
A: The SW-1373 is compatible with multiple Toyota electric lift trucks and other OEM manufacturers. Cross-reference part numbers include TY00591-60714-81, YT800058861, and 078927. Verify your specific model number before ordering.
Q: What terminal type does the SW-1373 use?
A: The SW-1373 features 0.250 inch male tab terminals for direct connection to panel-mount applications. The M12 threaded bushing provides secure panel mounting on electric lift truck control panels.
Q: What material is the SW-1373 housing made from?
A: The SW-1373 housing is constructed from glass-filled thermoset plastic, which provides durability and electrical insulation in industrial material handling environments.
Q: Can the SW-1373 handle momentary and continuous duty?
A: The SW-1373 is designed for SPST momentary operation, meaning it is intended for momentary activation rather than continuous holding duty. Use only in circuits and applications where momentary control is specified.
Q: What are the cross-reference part numbers for the SW-1373?
A: Equivalent part numbers include TY00591-60714-81, YT800058861, 078927, and SW1373. When ordering replacement switches, confirm the cross-reference matches your equipment manufacturer.
