Product Description
Toyota OEM switch (part number TO 00591-60663-81, TY00591-60663-81) designed for electric lift truck controls. Features SPST toggle actuator, 24VDC nominal rating, panel mountable with M12x1.0 threads, glass-filled nylon housing, stainless actuator, and silver-plated copper contacts. Rated for 50,000 actuations and 10A current capacity. Compatible with Toyota electric lift truck series.
Specifications
Material & Construction
| Switch Body Material | Glass-filled nylon with flame retardant formulation |
| Actuator Material | Stainless steel actuator lever, brushed finish |
Part Numbers
| OEM Part Number | TO 00591-60663-81 |
| Manufacturer Part Number | TY00591-60663-81 |
Performance
| Duty Cycle | Suitable for up to 120 cycles/hour continuous operation |
| Service Life | Rated for 50,000 actuations minimum |
Frequently Asked Questions
Q: What is the Toyota OEM switch TO 00591-60663-81 used for?
A: This is a factory OEM switch designed for electric lift truck controls in Toyota material handling equipment. It functions as an SPST (single pole, single throw) toggle switch rated for 24VDC nominal applications and is commonly used in control circuits for Toyota electric pallet jacks and lift trucks.
Q: What are the electrical specifications for part number TO 00591-60663-81?
A: This switch has a 24VDC nominal voltage rating, 10A current capacity, SPST toggle actuator configuration, and is rated for up to 50,000 actuations over its service life. It is suitable for continuous operation up to 120 cycles per hour.
Q: What materials is the TO 00591-60663-81 constructed from?
A: The switch body is made from glass-filled nylon with flame retardant formulation for durability and safety. The actuator is stainless steel with a brushed finish, and the contacts are silver-plated copper for reliable electrical conductivity and corrosion resistance.
Q: Which Toyota electric lift truck series is this switch compatible with?
A: This OEM switch is designed for Toyota electric lift truck series. Verify compatibility with your specific model before ordering. The part is panel mountable with M12x1.0 threads for secure installation in control panel applications.
Q: What is the cross-reference part number for TO 00591-60663-81?
A: The manufacturer part number is TY00591-60663-81, which is equivalent to the OEM part number TO 00591-60663-81. Both reference the same factory switch.
Q: How long does this switch typically last in continuous service?
A: The switch is rated for 50,000 actuations, which provides substantial service life in industrial lift truck applications. Expected lifespan depends on actual duty cycle and operating conditions. The stainless steel actuator and silver-plated contacts resist corrosion and wear, extending component life in demanding environments.
