Product Description
Barrett GWK-RPX60N-LW-XL Load Wheel Kit for electric lift trucks. Includes two 97A polyurethane load wheels with steel hubs, precision sealed ball bearings, alloy steel axles, and Grade 8 fasteners. Compatible with Barrett RPX60N electric pallet jack models. Cross-reference: replaces GWK-RPX60B-LW-XL, supersedes GWK-RPX60B-LW, and equivalent to GWK-RPX60N-LW.
Compatibility: Fits pallet jacks made by Barrett, model RPX60. SKU: GWK-RPX60N-LW-XL
Specifications
Material & Construction
| Polyurethane Specification | ISO 20129-certified 97A polyurethane tread |
| Steel Grade (Axle/Fasteners) | SAE Grade 8 steel, ASTM A574 specification |
Part Numbers
| Manufacturer Part Number | GWK-RPX60N-LW-XL |
| OEM Part Number | GWK-RPX60N-LW-XL |
| Cross-Reference Part Numbers | Replaces GWK-RPX60B-LW-XL, supersedes GWK-RPX60B-LW, equivalent to GWK-RPX60N-LW |
| Compatible Models | Barrett RPX60N series electric pallet trucks |
Frequently Asked Questions
Q: What equipment does the GWK-RPX60N-LW-XL wheel kit replace, and what are the cross-references?
A: GWK-RPX60N-LW-XL replaces GWK-RPX60B-LW-XL and supersedes GWK-RPX60B-LW. It is equivalent to GWK-RPX60N-LW. All three SKUs are interchangeable for Barrett RPX60 series jacks and provide the same 97A polyurethane performance profile.
Q: Are the GWK-RPX60N-LW-XL wheels compatible with both RPX60B and RPX60N model jacks?
A: Yes. GWK-RPX60N-LW-XL is designed for Barrett RPX60N and backward-compatible with RPX60B electric pallet jacks. The -XL designation indicates it covers the broader RPX60 product line. Verify your jack model number before installation.
Q: What is the wheel durometer rating and load capacity of the GWK-RPX60N-LW-XL kit?
A: GWK-RPX60N-LW-XL features 97A polyurethane load wheels with steel hubs, precision sealed ball bearings, and alloy steel axles. Standard RPX60 jacks support up to 1200 pounds, distributed across two wheels. The 97A durometer provides superior wear resistance.
Q: Does installation of the GWK-RPX60N-LW-XL require any equipment modifications?
A: No modifications are required. GWK-RPX60N-LW-XL is a direct bolt-on replacement. Remove the axle nuts using a socket, slide the old wheel assembly off, install the new kit onto the axle, and torque fasteners to specification. Grade 8 fasteners are included.
Q: How do you diagnose bearing failure on the GWK-RPX60N-LW-XL wheels?
A: Lift the jack and manually spin each wheel. Healthy sealed ball bearings allow smooth 15+ second rotation. If rotation stops within 3 seconds, produces grinding noise, or the wheel tilts side-to-side on the axle, bearing seals have failed and the wheel kit must be replaced.
Q: What maintenance is required to extend the service life of the GWK-RPX60N-LW-XL kit?
A: The sealed bearing design requires no lubrication or maintenance. Inspect wheels monthly for flat-spotting, tread loss, or debris lodged in the polyurethane. Clean wheels with a damp cloth to remove residue. Replace the entire kit when wheels no longer grip or show visible damage.
