Product Description
The RA 1053389 is a left-hand, open-toe wheel plate with sideshift mounting for Raymond electric reach trucks. This direct replacement assembly is engineered for the 7400, 7420, and 7440 series and supports 5-inch diameter load wheels. The factory-spec steel plate construction integrates with standard Raymond axle, spacer, and carrier hardware to deliver reliable performance in high-duty warehouse and distribution applications.
Specifications
Part Information
| Part Number | RA 1053389 |
| Configuration | Left-Hand, Open-Toe, With Sideshift |
Compatibility
| Compatible Lift Truck Models | Raymond 7400, 7420, 7440 Series Electric Reach Trucks |
| Load Wheel Diameter | 5 Inches |
Material & Construction
| Material | High-Strength Steel Plate Fabrication |
Cross-Reference & Associated Parts
| Replaces | RA 1049978, RA 1053385 (Closed Wheel Plates, Left-Hand) |
| Right-Hand Equivalent | RA 1053390 |
| Associated Hardware Components | Screw RA 1040923/005, Shoulder Bolt RA 5-005-017, Lock Nut RA 5-016-017, Plate Carrier RA 623-010-109, Spacer RA 1031101, Load Wheel Axle RA 1014758/001 (2.88" Wide), Axle RA 1014758/002 (3.62" Wide), Lube Fitting RA 841-111 |
Frequently Asked Questions
Q: What Raymond electric reach truck models does the RA 1053389 wheel plate fit?
A: The RA 1053389 is engineered for Raymond 7400, 7420, and 7440 series electric reach trucks. This is a left-hand, open-toe configuration wheel plate with sideshift support. Verify your truck series before ordering.
Q: What load wheel diameter is the RA 1053389 compatible with?
A: This wheel plate assembly is designed for 5 inch diameter load wheels. It works with standard Raymond axle, spacer, and carrier hardware. Check your current load wheel specifications to confirm compatibility.
Q: What are the cross-reference part numbers for the RA 1053389?
A: The RA 1053389 replaces closed-plate alternatives RA 1049978 and RA 1053385 (both left-hand). The right-hand equivalent is RA 1053390. Use these part numbers if you need to verify fitment across truck configurations.
Q: What hardware components are required with the RA 1053389 wheel plate?
A: The assembly uses Screw RA 1040923/005, Shoulder Bolt RA 5-005-017, and Lock Nut RA 5-016- as standard Raymond OEM hardware. All hardware must be present and properly torqued for safe operation.
Q: Is the RA 1053389 a left-hand or right-hand wheel plate?
A: The RA 1053389 is a left-hand configuration. If you need a right-hand plate for the opposite side of your truck, the equivalent part is RA 1053390.
Q: What is the material and durability of the RA 1053389 wheel plate?
A: This is a high-strength steel component engineered for commercial electric reach truck duty. The open-toe design accommodates standard load wheel assemblies while the sideshift configuration allows lateral positioning. Steel construction provides durability in warehouse and distribution environments.
